技术规格 |
HFC-1808TMNC-17A | HFC-1206T | HFC-1808T | HFC-1810T | HFC-1812T | HFC-1808H | HFC-1810H | HFC-1206H | HFC-2408H | HFC-1206TNC | HFC-1810TNC | HFC-1812TNC | HFC-1808HNC | HFC-1206TMNC-17A | HFC-1810TMNC-17A | HFC-1206HMNC-17A | HFC-1808HMNC-17A | HFC-1810HMNC-17A | HFC-2012HMNC-17A | HFC-2408HFNC | HFC-2008HNC | HFC-1808TNC | HFC-1810HNC | HFC-2012HNC | HFC-1206HNC | HFC-1812TMNC-17A | HFC-1808ENC-72A | HFC-1808HFNC-76A | HFC-1808HFNC-74A |
| 砂轮 |
标准刀架加工直径 |
Φ1～Φ50mm | Φ1～Φ35mm | Φ1～Φ50mm | Φ1～Φ50mm | Φ1～Φ50mm | Φ1～Φ50mm | Φ1～Φ50mm | Φ1～Φ35mm | Φ1～Φ100mm | Φ1～Φ35mm | Φ1～Φ50mm | Φ1～Φ50mm | Φ1～Φ50mm | Φ1～Φ40mm | Φ1～Φ50mm | Φ1～Φ40mm | Φ1～Φ50mm | Φ1～Φ50mm | Φ1～Φ60mm | Φ1～Φ100mm | Φ1～Φ50mm | Φ1～Φ50mm | Φ1～Φ50mm | Φ1～Φ60mm | Φ1～Φ40mm | Φ1～Φ50mm | Φ1～Φ50mm | Φ1～Φ50mm | Φ1～Φ50mm |
特别刀架加工直径 |
Φ40～Φ120mm | Φ40～Φ60mm | Φ40～Φ120mm | Φ40～Φ120mm | Φ40～Φ100mm | Φ40～Φ120mm | Φ40～Φ120mm | Φ40～Φ60mm | Φ40～Φ120mm | Φ30～Φ60mm | Φ40～Φ100mm | Φ40～Φ100mm | Φ40～Φ100mm | Φ35～Φ60mm | Φ40～Φ120mm | Φ35～Φ60mm | Φ40～Φ120mm | Φ40～Φ120mm | Φ50～Φ180mm | Φ30～Φ120mm | Φ40～Φ150mm | Φ40～Φ100mm | Φ40～Φ100mm | Φ50～Φ180mm | Φ30～Φ60mm | Φ40～Φ120mm | Φ40～Φ100mm | Φ40～Φ100mm | Φ40～Φ100mm |
研磨砂轮尺寸 (外径x宽x内径) |
Φ455×205×Φ228.6 | Φ305×150×Φ120 | Φ455x205xΦ228.6 | Φ455×225×Φ228.6 | Φ455×305×Φ228.6 | Φ455×205×Φ228.6 | Φ455x255xΦ228.6 | Φ305×150×Φ120mm | Φ610x205xΦ304.8 | Φ305×150×Φ120 | Φ455x255xΦ228.6 | Φ455×305×Φ228.6 | Φ455×205×Φ228.6 | Φ305×150×Φ120 | Φ455x255xΦ228.6 | Φ305x150xΦ120 | Φ455x205xΦ228.6 | Φ455x255xΦ228.6 | Φ510x305xΦ245 | Φ610x205xΦ304.8 | Φ510x205xΦ254 | Φ455x205xΦ228.6 | Φ455x255xΦ228.6 | Φ510x305xΦ254 | Φ305x150xΦ120 | Φ455x305xΦ228.6 | Φ455×205×Φ228.6 | Φ455×205×Φ228.6 | Φ455×205×Φ228.6 |
导轮尺寸（外径x宽x内径） |
Φ255×205×Φ111.2 | Φ205×150×Φ90 | Φ255x205xΦ111.2 | Φ455×225×Φ111.2 | Φ455×305×Φ111.2 | Φ455×205×Φ111.2 | Φ455x255xΦ111.2 | Φ205×150×Φ90mm | Φ305x205xΦ165 | Φ205×150×Φ90 | Φ255x255xΦ111.2 | Φ255×305×Φ111.2 | Φ255×205×Φ111.2 | Φ205×150×Φ90 | Φ255x255xΦ111.2 | Φ205x150xΦ90 | Φ255x205xΦ111.2 | Φ255x255xΦ111.2 | Φ355x305xΦ150 | Φ330x205xΦ203.2 | Φ305x205xΦ127 | Φ255x205xΦ111.2 | Φ255x255xΦ111.2 | Φ355x305xΦ150 | Φ205x150xΦ90 | Φ255x305xΦ111.2 | Φ255×205×Φ111.2 | Φ255×205×Φ111.2 | Φ255×205×Φ111.2 |
| 主轴 |
主轴形式 |
动压型 | 动压型 | 动压型 | 动压型 | 动压型 | 液静压型 | 液静压型 | 液静压型 | 高液静压型 | 动压型 | 动压型 | 动压型 | 液静压型 | 动压型 | 动压型 | 液静压型 | 液静压型 | 液静压型 | 液静压型 | 液静压型 | 液静压型 | 动压型 | 液静压型 | 液静压型 | 液静压型 | 动压型 | 动压型 | 液静压型 | 液静压型 |
主轴旋转精度 |
〈0.002mm | ＜0.002mm | ＜0.002mm | ＜0.002mm | ＜0.002mm | ＜0.001mm | ＜0.001mm | ＜0.0015mm | ＜0.0015mm | ＜0.002mm | ＜0.002mm | ＜0.002mm | ＜0.0015mm | ＜0.002mm | ＜0.002mm | ＜0.0015mm | ＜0.0015mm | ＜0.0015mm | ＜0.0015mm | / | 〈0.0015mm | 〈0.002mm | 〈0.0015mm | 〈0.0015mm | 〈0.0015mm | 〈0.002mm | ＜0.0015mm | ＜0.0015mm | ＜0.0015mm |
| 调整轮 |
导轮传动方式 |
链条传动 | 链条传动 | 链条传动 | 链条传动 | 链条传动 | 蜗轮减速机传动 | 蜗轮减速机传动 | 蜗轮减速机传动 | 蜗轮减速机传动 | 链条传动 | 链条传动 | 链条传动 | 蜗轮减速机传动 | 链条传动 | 链条传动 | 蜗轮减速机传动 | 蜗轮减速机传动 | 蜗轮减速机传动 | 蜗轮减速机传动 | / | 蜗轮减速机传动 | 链条传动 | 蜗轮减速机传动 | 蜗轮减速机传动 | 蜗轮减速机传动 | 链条传动 | 行星减速机同步带链轮传动 | | |
供油压力 |
10kg±1kg | 10kg±1kg | 10kg | 10kg | 10kg | 25kg | 25kg | 25kg±1kg | 20-25kg/cm² | 5-10kg/cm² | 5-10kg/cm² | 5-10kg/cm² | 25kg±1kg | 10kg±1kg | 10kg±1kg | 25kg±1kg | 25kg±1kg | 25kg±1kg | 25kg±1kg | / | 25kg±1kg | 5-10kg/cm² | 25kg±1kg | 25kg±1kg | 25kg±1kg | 10kg±1kg | 20-25kg/cm2 | 25±1kg/cm² | 25±1kg/cm² |
研磨砂轮转速 |
1520R.P.M | 1950R.P.M | 1520R.P.M | 1520R.P.M | 1520R.P.M | 600-2000R.P.M | 600-2000R.P.M | 1950R.P.M(600-2500) | 900-1500R.P.M | 1950R.P.M | 1520R.P.M | 1520R.P.M | 1520（600-2000）R.P.M | 1950R.P.M | 1520R.P.M | 1950R.P.M(600-2500R.P.M) | 1950R.P.M(600-2500R.P.M) | 1950R.P.M(600-2500R.P.M) | 1380R.P.M(600-1800R.P.M) | 900-1500R.P.M | 1350（600-1800）R.P.M | 1520R.P.M | 1520（600-2000）R.P.M | 1380(600-1800)R.P.M | 1950（600-2500）R.P.M | 1520R.P.M | 600-1520 R.P.M | 1520 R.P.M | 1520 R.P.M |
导轮转速 |
1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 10-250R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300R.P.M | 1-300 R.P.M | 1-300 R.P.M |
| 驱动马达 |
砂轮驱动马达 |
| 7.5HP(5.5KW) AC380V/50Hz | 15HP(11KW) AC380/50Hz | 15HP(11KW) AC380/50Hz | 20HP(15KW) AC380/50Hz | 15HP(11KW) AC380/50Hz | 15HP(11KW) AC380/50Hz | 7.5HP(5.5KW) AC380V/50Hz | 30HP(22KW)AC200/50Hz | 7.5HP(5.5KW)AC380V/50Hz | 15HP(11KW) AC380V/50Hz | 20HP(15KW) AC380/50Hz | 15HP(11KW) AC380/50Hz | 7.5HP(5.5KW) AC380V/50Hz | 15HP(11kw)AC380V/50Hz | 7.5HP(5.5KW) AC380V/50Hz | 15HP(11KW) AC380/50Hz | 15HP(11KW) AC380/50Hz | 30HP(22KW) AC380/50Hz | 30HP(22KW) AC220V/50Hz | 20HP(15KW) AC380/50Hz | 15HP(11kw)AC380V/50Hz | 15HP(11kw)AC380V/50Hz | 30HP(22KW)AC380/50Hz | 7.5HP(5.5kw)AC380V/50Hz | 20HP(15kw)AC380V/50Hz | 15HP(11kw)AC380V/50HZ | 15HP(11kW) AC380V/50Hz | 15HP(11kW) AC380/50Hz |
导轮驱动马达 |
| 2.6HP(2KW) AC200V/50Hz | 4HP(3KW) AC200/50Hz | 4HP(3KW) AC200/50Hz | 4HP(3KW) AC200/50Hz | 4HP(3KW) AC200/50Hz | 4HP(3KW) AC200/50Hz | 2.6HP(2KW) AC200V/50Hz | 4HP(3KW)AC200/50Hz | 2.6HP(2KW)AC200V/50Hz | 4HP(3KW) AC200V/50Hz | 4HP(3KW) AC200/50Hz | 4HP(3KW) AC220/50Hz | 2.6HP(2KW) AC200V/50Hz | 4HP(3KW) AC200/50Hz | 2.6HP(2KW) AC200V/50Hz | 4HP(3KW) AC200/50Hz | 4HP(3KW) AC200/50Hz | 4HP(4.5KW) AC200/50Hz | 6.6HP(5KW) AC200V/50Hz | 4HP(3KW) AC200/50Hz | 4HP(3kw)AC200V/50Hz | 4HP(3kw)AC200V/50Hz | 6HP(4.5KW)AC200/50Hz | 2.0kw AC200V/50Hz | 4HP(3kw)AC200/50Hz | 4HP(3.0kW)AC220V/50HZ | 4HP(3kW) AC200V/50Hz | 4HP(3kW) AC200/50Hz |
油压驱动马达 |
1HP(0.75KW) AC380V/50Hz | 1HP(0.75KW) AC380V/50Hz | 1HP(0.75KW) AC380/50Hz | 1HP(0.75KW) AC380/50Hz | 1HP(0.75KW) AC380/50Hz | 2HP(1.5KW) AC380/50Hz | 2HP(1.5KW) AC380/50Hz | 1HP(0.75KW) AC380V/50Hz | 2HP(1.5KW)AC380/50Hz | 1HP(0.75KW)AC380V/50Hz | 1HP(0.75KW) AC380V/50Hz | 1HP(0.75KW) AC380/50Hz | 2HP(1.5KW) AC380/50Hz | 1HP(0.75KW) AC380V/50Hz | 1HP(0.75KW) AC380/50Hz | 1HP(0.75KW) AC380V/50Hz | 1HP(0.75KW) AC380/50Hz | 1HP(0.75KW) AC380/50Hz | 1HP(0.75KW) AC380/50Hz | 2HP(1.5KW) AC380V/50Hz | 2HP(1.5KW) AC380/50Hz | 1HP(0.75kw)AC380V/50Hz | 2HP(1.5kw)AC380V/50Hz | 2HP(1.5KW)AC380/50Hz | 1HP(0.75kw)AC380V/50Hz | 1HP(0.75kw)AC380V/50Hz | 2HP(1.5kW )AC380V/50HZ | 2HP(1.5kW) AC380/50Hz | 2HP(1.5kW) AC380/50Hz |
冷却驱动马达 |
1/4HP(180W) AC380V/50Hz | 1/8HP(90W) AC380V/50Hz | 1/4HP(180W) AC380/50Hz | 1/4HP(180W) AC380/50Hz | 1/4HP(180W) AC380/50Hz | 1/4HP(180W) AC380/50Hz | 1/4HP(180W) AC380/50Hz | 1/8HP(90W) AC380V/50Hz | 2HP(1.5KW)AC380/50Hz | 1/8HP(90W)AC380V/50Hz | 1/4HP(180W) AC380V/50Hz | 1/4HP(180W) AC380/50Hz | 1/4HP(180W) AC380/50Hz | 1/8HP(90W) AC380V/50Hz | 1/4HP(180W) AC380/50Hz | 1/8HP(90W) AC380V/50Hz | 1/4HP(180W) AC380/50Hz | 1/4HP(180W) AC380/50Hz | 1/4HP(180W) AC380/50Hz | 1/4HP(180W) AV380V/50Hz | 1/4HP(180W) AC380/50Hz | 1/4HP(180w)AC380V/50Hz | 1/4HP(180w)AC380V/50Hz | 1HP(750W)AC380/50Hz | 1/8HP(90w)AC380V/50Hz | 1/4HP(180w)AC380V/50Hz | 1/4 HP(180w)AC380V/50HZ | 1/4HP(180W) AC380/50Hz | 1/4HP(180W) AC380/50Hz |
工作台驱动马达 |
| | | | | | | | | | | | | 1KW AC200/50Hz | 1.5KW AC200V/50Hz | 1KW AC200/50Hz | 1.5KW AC200V/50Hz | 1.5KW AC200/50Hz | 3KW AC200/50Hz | / | | | | | | 1.5kw AC380V/50Hz | | 1.4kW AC220/50Hz | 1.4kW AC200V/50Hz |
工作台进给精度 |
| | | | | | | | | | | | | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | / | | | | | | 0.001mm | | 0.001mm | 0.001mm |
导轮进给驱动马达 |
| | | | | | | | | | | | | 1KW AC200/50Hz | 1KW AC200/50Hz | 1KW AC200V/50Hz | 1kw AC200/50Hz | 1KW AC200/50Hz | / | / | | | | | | 1kw AC200/50Hz | | | |
导轮进给精度 |
| | | | | | | | | | | | | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | / | | | | | | 0.001mm | | | |
| 手轮 |
导轮进刀手轮 |
/ | 3.5mm/rotation 0.02mm/graduation | 3.5mm/rotation 0.05mm/graduation | 3.5mm/rotation 0.05mm/graduation | 3.5mm/rotation 0.05mm/graduation | 3.5mm/rotation 0.05mm/graduation | 3.5mm/rotation 0.05mm/graduation | 3.5mm/rotation 0.02mm/graduation | 4mm/rotation 0.02mm/graduation | 3.5mm/rotation 0.02mm/graduation | 3.5mm/rotation 0.05mm/graduation | 3.5mm/rotation 0.05mm/graduation | 3.5mm/rotation 0.05mm/graduation | / | / | / | / | / | / | / | 3.5mm/rotation 0.05mm/graduation | 3.5mm/rotation 0.05mm/graduation | 3.5mm/rotation 0.05mm/graduation | 3.5mm/rotation 0.05mm/graduation | 4mm/rotation 0.02mm/graduation | / | 3.5mm/每转 0.05mm/每刻度 | | |
导轮微调手轮 |
/ | / | 0.1mm/rotation 0.001mm/graduation | 0.1mm/rotation 0.001mm/graduation | 0.1mm/rotation 0.001mm/graduation | 0.1mm/rotation 0.001mm/graduation | 0.1mm/rotation 0.001mm/graduation | / | / | / | 0.1mm/rotation 0.001mm/graduation | 0.1mm/rotation 0.001mm/graduation | 0.1mm/rotation 0.001mm/graduation | / | / | / | / | / | / | / | 0.1mm/rotation 0.001mm/graduation | 0.1mm/rotation 0.001mm/graduation | 0.1mm/rotation 0.001mm/graduation | 0.1mm/rotation 0.001mm/graduation | / | / | 0.1mm/每转 0.001 mm/每刻度 | | |
工作台进刀手轮 |
/ | 7mm/rotation 0.05mm/graduation | 9mm/rotation 0.10mm/graduation | 9mm/rotation 0.10mm/graduation | 9mm/rotation 0.10mm/graduation | 9mm/rotation 0.10mm/graduation | 9mm/rotation 0.10mm/graduation | 7mm/rotation 0.05mm/graduation | 7mm/rotation 0.05mm/graduation | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / | | | |
工作台微调手轮 |
/ | 0.2mm/rotation 0.001mm/graduation | 0.2mm/rotation 0.001mm/graduation | 0.2mm/rotation 0.001mm/graduation | 0.2mm/rotation 0.001mm/graduation | 0.2mm/rotation 0.001mm/graduation | 0.2mm/rotation 0.001mm/graduation | 0.2mm/rotation 0.001mm/graduation | 0.2mm/rotation 0.001mm/graduation | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / | | | |
修整进刀手轮 |
/ | 1.5mm/rotation 0.01mm/graduation | 2mm/rotation 0.01mm/graduation | 2mm/rotation 0.01mm/graduation | 2mm/rotation 0.01mm/graduation | 2mm/rotation 0.01mm/graduation | 2mm/rotation 0.01mm/graduation | 1.5mm/rotation 0.01mm/graduation | 1.25mm/rotation 0.01mm/graduation | 1.5mm/rotation 0.01mm/graduation | 2mm/rotation 0.01mm/graduation | 2mm/rotation 0.01mm/graduation | 2mm/rotation 0.01mm/graduation | / | / | / | / | / | / | / | 2mm/rotation 0.01mm/each graduation | 2mm/rotation 0.01mm/graduation | 2mm/rotation 0.01mm/graduation | 2mm/rotation 0.01mm/graduation | 1.5mm/revolution 0.01mm/each graduation | / | | | |
导轮倾斜角度 |
+5°～-3° | +5°～-3° | +6°～-5° | +6°～-5° | +6°～-5° | +6°～-5° | +6°～-5° | +6°～-5° | +5°～-3° | +5°～-3° | +6°～-5° | +6°～-5° | +6°～-5° | +5°～-3° | +6°～-5° | +5°～-3° | +6°～-5° | +6°～-5° | +6°～-5° | +5°～-3° | +6°～-5° | +6°～-5° | +6°～-5° | +6°～-5° | +5°～-3° | +6°～-5° | +6°～- 3° | +6°~-5° | +6°~-5° |
导轮旋转角度 |
±6° | ±5° | ±5° | ±6° | ±6° | ±6° | ±6° | ±6° | ±5° | ±5° | ±6° | ±6° | ±5° | ±5° | ±6° | ±5° | ±6° | ±6° | ±6° | ±5° | ±6° | ±6° | ±6° | ±6° | ±5° | ±6° | ±6° | ±6° | ±6° |
| 数控单元 |
砂轮修整进给精度X1,Z1 |
| | | | | | | | | | | | | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | / | | | | | | 0.001mm | 0.001mm | 0.001mm | 0.001mm |
导轮修整进给精度X2,Z2 |
| | | | | | | | | | | | | 0.4KW AC200/50Hz 0.75KW AC200/50Hz | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | / | | | | | | 0.001mm | 0.001mm | 0.001mm | |
工作台进给伺服单元 |
| / | / | / | / | / | / | / | / | 1.5kw AC200V/50Hz | 2.0KW AC220V/50Hz | 2.0KW AC220V/50Hz | 1.5KW AC200V/50Hz | / | / | / | / | / | / | / | 2HP(1.5KW)AC200V/50Hz | 2.0kw AC220V/50Hz | 1.5kw AC200V/50Hz | 4HP(3kw)AC200V/50Hz | 1.0kw AC200V/50Hz | / | 2.0kW/AC200V | | |
工作台进给分辨率 |
| | | | | | | | | | | | 0.001mm | / | / | / | / | / | / | / | 0.001mm | | 0.001mm | 0.0001mm | 0.001mm | / | 0.0001mm | | 0.0001mm |
工作台进给精度（Y1) |
| / | / | / | / | / | / | / | / | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | / | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | 0.001mm | |
砂轮修整驱动马达X1,Z1 |
| / | / | / | / | / | / | / | / | / | / | / | / | 0.4KW AV200V/50Hz 0.75KW AC200V/50Hz | 0.4KW AV200V/50Hz 0.75KW AC200V/50Hz | 0.4KW AV200V/50Hz 0.75KW AC200V/50Hz | 0.4KW AV200V/50Hz 0.75KW AC200V/50Hz | 0.4KW AV200V/50Hz 0.75KW AC200V/50Hz | 0.75KW AV200V/50Hz 1KW AC200V/50Hz | / | / | / | / | / | / | 0.4KW AC200/50Hz 0.75KW AC200/50Hz | | 0.5kW 0.75kW AC200/50Hz | 0.5kW 0.75kW AC200/50Hz |
导轮修整驱动马达X2，Z2 |
| / | / | / | / | / | / | / | / | / | / | / | / | 0.4KW AC200V/50Hz 0.75kW AC200V/50Hz | 0.4KW AC200V/50Hz 0.75kW AC200V/50Hz | 0.4KW AC200V/50Hz 0.75kW AC200V/50Hz | 0.4KW AC200V/50Hz 0.75kW AC200V/50Hz | 0.4KW AC200V/50Hz 0.75kW AC200V/50Hz | 0.75KW AC200V/50Hz 1kW AC200V/50Hz | / | / | / | / | / | / | 0.4KW AC200/50Hz 0.75KW AC200/50Hz | | 0.5kW 0.75kW AC200/50Hz | |
送收料机械臂驱动马达（B1,B2) |
| / | / | / | / | / | / | / | / | / | / | / | / | 0.4KW AC200/50Hz | 0.4KW AC200V/50Hz | 0.4KW AC200V/50Hz | 0.4KW AC200V/50Hz | 0.4KW AC200V/50Hz | 0.4KW AC200V/50Hz 0.4kW AC200V/50Hz | / | / | / | / | / | / | 0.4KW AC200/50Hz | | 0.4kW AC200/50Hz | 0.4kW AC200/50Hz |
送收料机械臂进给精度（B1,B2) |
| / | / | / | / | / | / | / | / | / | / | / | / | 0.01mm | 0.01mm | 0.01mm | 0.01mm | 0.01mm | 0.01mm | / | / | / | / | / | / | 0.01mm | | 0.02mm | 0.02mm |
| 规格 |
机械尺寸 |
2350×1960×1550mm | 1800x1400x1450mm | 2350x1960x1550mm | 2350x1960x1550mm | 2350x1960x1550mm | 2350x1960x1550mm | 2350x1960x1550mm | 1800x1400x1450mm | 1500x2600x1850mm | 1800x1400x1450mm | 2350x1960x1550mm | 2350x1960x1550mm | 2350x1960x1550mm | 1800x1400x1450mm | 2350x1960x1550mm | 1800x1400x1450mm | 2350x1960x1550mm | 2350x1960x1550mm | 4500x2700x2300mm | 3300x3000x2700mm | 2350x1960x1550mm | 2350x1960x1550mm | 2350x1960x1550mm | 4500x2600x2100mm | 1800x1400x1450mm | 2350x1960x1550mm | 2350×1960×1550mm | 2750×1960×1550mm | 2750×1960×1550mm |
装箱尺寸 |
2400×2000×1800mm | 2000x1700x1700mm | 2400x2000x1800mm | 2400x2000x1800mm | 2400x2000x1800mm | 2400x2000x1800mm | 2400x2000x1800mm | 2000x1700x1700mm | 2000x3300x2000mm | 2000x1700x1700mm | 2400x2000x1800mm | 2400x2000x1800mm | 2400x2000x1800mm | 2000x1700x1800mm | 2400x2000x1800mm | 2000x1700x1800mm | 2400x2000x1800mm | 2400x2000x1800mm | 4600x2700x2350mm | / | 2400x2000x1800mm | 2400x2000x1800mm | 2400x2000x1800mm | 4600x2700x2200mm | 2000x1700x1700mm | 2400x2000x1800mm | 2400×2000×1800mm | 3800×2000×1800mm | 3800×2000×1800mm |
机械重量 |
2850kg | 1770kgs | 2850kgs | 2950kgs | 3050kgs | 2850 kgs | 2950 kgs | 1770 kgs | 3185kgs | 1770 kgs | 2950 kgs | 3050 kgs | 2850 kgs | 1770 kgs | 2950 kgs | 1770 kgs | 2850 kgs | 2950 kgs | 5800 kgs | 4500kgs | 2950 kgs | 2850 kgs | 2950 kgs | 5500 kgs | 1770 kgs | 3050 kgs | 3400Kg | 3300 kg | 3300 kg |
装箱重量 |
3005 kg | 1920kgs | 3005kgs | 3150kgs | 3250kgs | 3005 kgs | 3150 kgs | 1920 kgs | 3321kgs | 1920 kgs | 3150 kgs | 3250 kgs | 3005 kgs | 1920 kgs | 3150 kgs | 1920 kgs | 3005 kgs | 3150 kgs | 6000 kgs | / | 3150 kgs | 3005 kgs | 3150 kgs | 5600 kgs | 1920 kgs | 3250 kgs | 3450Kg | 3800 kg | 3800 kg |
